AN ODE TO ANALOG
Jolene™ is a 4-way, 12 element hybrid in-ear monitor. The driver configuration combines balanced armature and dynamic components. The LF band (20Hz- 400Hz) uses a pair of 9.2mm dynamic drivers. These diaphragms provide for an excellent sub-bass punch. The mid-range (400Hz-4KHz) is powered by two 4.9mm dynamic drivers that produce a very natural low-end bass with exceptional tonality and rich texture. The High-Mids (4KHz - 10KHz) and HF bands (10KHz - 23KHz) are both powered by quad balanced armatures, similar to the JH Audio Roxanne. The tonality of the dynamics blended with the balanced armatures creates a wonderfully balanced IEM. Jolene is the most natural, analog-sounding IEM Jerry has ever designed.
Jolene is available in two Signature Designs, free of charge. Navigate to the JOLENE tab under SHELL selection in our 3D Designer to view each design. Please note, all other design upgrades will be full price.
Estimated lead time 12-14 business days • 16-18 business days for Upgraded Shells
Rush services available - Email firstname.lastname@example.org
Freq|phase™ Technology creates the most phase accurate IEMs on the market by correcting misalignment caused by low, mid, and high frequencies traveling to your ear at different speeds.
Soundrive™ Technology utilizes our proprietary mini quad drivers. This allows our Custom IEMs to remain smaller in size while housing up to 12 drivers per side.
ACOUSTIC SOUND CHAMBER
Acoustic Sound Chamber™ is a 3D printed, recessed tubing system that is the first of its kind, keeping sweat at bay and alleviating the need for excessive cleaning.
- Hyrbid Driver Configuration (12 per side)
- Dual Low Opposing Dynamic Drivers using Dome™ Technology
- Dual Low-Mid Dynamic Drivers using Dome™ Technology
- Powered by Soundrive Technology: Quad High-Mid BA, Quad Ultra-High BA
- Premium 7-Pin Litz Wire Connector with Built-in O-ring
- High Purity OFC 4N Silver-plated Cable
- Variable Bass Attenuator (0 to +15dB)
- Triple Bore with Freqphase Stainless Steel Tube Waveguide
- Input Connector: 1/8" (3.5mm), Gold-Plated
- Integrated 4-way Crossover
- Frequency Response: 20 Hz to 23 kHz
- Impedence: 10 Ω
- Input Sensitivity: 114 dB @ 1mW
- Noise Isolation: -26 dB
- Jolene Custom In-Ear Monitors
- Premium Litz Wire Cable
- A personalized JH Audio Carbon Fiber IEM Case
- Wax Tool
- Bass Adjustment Tool
- Flygirl Sticker
- Owner's Manual
